A robot recreates the walk of a 300-million-year-old animal

© 2019 Maxime Marendaz - OroBOT can recreate the Orobates pabsti's walk.

© 2019 Maxime Marendaz - OroBOT can recreate the Orobates pabsti's walk.

Using the fossil and fossilized footprints of a 300-million-year-old animal, an interdisciplinary team that includes scientists from EPFL and Humboldt-Universität zu Berlin have developed a method for identifying the most likely gaits of extinct animals and designed a robot that can recreate their walk. This innovative study of animal biomechanics using robots can help researchers better understand how vertebrate locomotion evolved over time.


How did vertebrates walk 300 million years ago? Could they already stand upright on their legs? Did they move in a balanced, energy-efficient way? Scientists at EPFL’s Biorobotics Laboratory and the Interdisciplinary Laboratory Image Knowledge Gestaltung at Humboldt-Universität zu Berlin set out to answer these questions. Using the fossilized skeleton and footprints of Orobates pabsti – a vertebrate that, on the evolutionary tree, comes between amphibians on one hand and reptiles and mammals on the other – the scientists created computer simulations and a robot. Drawing on experimental studies of four living amphibian and reptile species, they used these tools to gauge how plausible different ways of walking were for the fossilized animal.

Orobates is an ideal candidate for understanding how land vertebrates evolved because it is in the lineage leading to modern amniotes. These animals formed in eggs laid on land and became largely independent of water,” says John Nyakatura, a professor at Humboldt-Universität. What’s more, Orobates is the oldest-known vertebrate for which scientists have been able to link a fossil with its fossilized footprints. “This combination is what enabled us to carry out our unique quantitative study, which paves the way to replicating the walk of other fossilized animals,” says Auke Ijspeert, a professor at EPFL’s School of Engineering. The researchers’ findings appear in Nature.

A motion-based model and then a robotic one

To better understand how Orobates walked and pinpoint just how advanced its locomotion was, the scientists at Humboldt-Universität developed a digital model of its skeleton based on the animal’s fossil and the biomechanics of modern animals with sprawling postures. They used this model to carry out the first kinematic computer simulation of Orobates’ gait as it walks on its digitalized footprints. This simulation focuses on movements (rather than forces) and identifies gaits where the animal’s bones do not collide or come out of their joints.

In parallel, two scientists at EPFL’s Biorobotics Laboratory – post-doctoral researcher Kamilo Melo and PhD student Tomislav Horvat – used the fossilized animal anatomy to build a robot called OroBOT. Designed and scaled to match the shape and movements of the extinct animal, OroBOT was used to calculate the physics of how Orobates walked. “We tested our hypotheses about the animal’s locomotion dynamics with our robotic model, which factors in the real-world physics of the animal’s gait,” says Melo.

Testing hundreds of different gaits, based on contemporary animals

The interdisciplinary team of scientists tested hundreds of different gaits with their robot in order to determine which ones Orobates could have used – and those that it clearly did not. The gaits they tested were based on biomechanical principles extracted from similar modern-day animals such as caimans, salamanders, iguanas and skinks, which they analyzed through X-ray videos and force measurements. “We studied the biomechanics of their movements and determined which mechanical principles they all followed,” says Nyakatura. The research team looked at three features in particular: how erect the animal stood on its legs; how its backbone bent; and how much its elbow or shoulder joints bent as it walked. These three features determine what the researchers call the animal’s “sprawling gait space.” They created a powerful interactive website where fellow scientists – and the wider public – can explore the universe of movements that Orobates could have used.

With these results, they came up with the most likely ways that Orobates may have walked. They scored the gaits based on how much energy was required, how stable the movements were, how the leg forces compared with those of other sprawling animals, and how closely the movements aligned with the fossilized footprints. The gaits with good scores appear quite athletic and most closely resemble the movements of caimans. This suggests that Orobates probably already held itself a little upright on its legs – unlike salamanders and skinks. Its locomotion was thus more advanced than had been previously thought.

The study concludes that advanced — more upright, balanced and mechanically power-saving —locomotion, as in Orobates, may have evolved before the common ancestor of reptiles and mammals lived. The novel approach developed for this study can be applied by other scientists in their work, and it could be modified to study other evolutionary transitions, such as the origins of flight or galloping gaits in mammals.

Contacts

For inquiries about robotics, in English or Spanish:

Kamilo Melo (robotics engineer, EPFL, Lausanne, Switzerland)

Email: [email protected]

For inquiries about robotics, in French:

Auke J. Ijspeert (head of the Biorobotics Laboratory, EPFL, Lausanne, Switzerland)

Email: [email protected]

For inquiries about biology and paleontology, in English and German:

John Nyakatura (biologist, Humboldt Universität zu Berlin, Berlin, Germany)

Email: [email protected]

Funding

*The Volkswagen Foundation (AZ 90222)

*The Daimler and Benz Foundation (32-08/12)

*The German Research Council (DFG EXC 1027)

*The Swiss National Science Foundation through NCCR Robotics

*The UK Natural Environment Research Council (NE/K004751/1)

References

John A. Nyakatura, Kamilo Melo, Tomislav Horvat, Kostas Karakasiliotis, Vivian R. Allen, Amir Andikfar, Emanuel Andrada, Patrick Arnold, Jonas Lauströer, John R. Hutchinson, Martin S. Fischer and Auke J. Ijspeert. “Reverse-engineering the locomotion of a stem amniote,” Nature, 17 January 2019.

http://dx.doi.org/10.1038/s41586-018-0851-2

This research was a collaborative effort among:

*AG Morphologie und Formengeschichte, Institut für Biologie, Humboldt Universität zu Berlin, Berlin, Germany.

*Bild Wissen Gestaltung. Ein interdisziplinäres Labor, Humboldt Universität zu Berlin, Berlin, Germany.

*Biorobotics Laboratory, École Polytechnique Fédérale de Lausanne (EPFL), Lausanne, Switzerland.

*Structure & Motion Laboratory, Department of Comparative Biomedical Sciences, the Royal Veterinary College, North Mymms, UK.

*Fakultät Design, Medien und Information, Department Design, Hochschule für Angewandte Wissenschaften, Hamburg, Germany.

*Institut für Zoologie und Evolutionsforschung mit Phyletischem Museum, Ernst-Haeckel-Haus und Biologiedidaktik, Friedrich-Schiller-Universität Jena, Jena, Germany.

*Knowledge Visualisation, Zürcher Hochschule der Künste, Zurich, Switzerland.


Author: Clara Marc
